| Beam angle of light source | -
°
|
| Lamp colour code | 840 neutral white
|
| Light source replaceable | No
|
| Number of gear units | One unit
|
| Driver/power unit/transformer | -
|
| Driver included | Yes
|
| Optic type | Wide beam
|
| Optical cover/lens type | Polystyrene bowl/cover prismatic
|
| Luminaire light beam spread | 90°
|
| Control interface | -
|
| Connection | Internal connector
|
| Cable | -
|
| Protection class IEC | Safety class II
|
| Glow-wire test | Temperature 650 °C, duration 30 s
|
| Flammability mark | -
|
| CE mark | CE mark
|
| ENEC mark | -
|
| Warranty period | 3 years
|
| Constant light output | No
|
| Number of products on MCB (16 A type B) | 20
|
| EU RoHS compliant | Yes
|
| Light source engine type | LED
|
| Service Tag | Yes
|
| Input Voltage | 220 to 240
V
|
| Input frequency | 50 to 60
Hz
|
| Initial CLO power consumption | NA
W
|
| Average CLO power consumption | NA
W
|
| Inrush current | 16
A
|
| Inrush time | 160
ms
|
| Power factor (min.) | 0.9
|
| Dimmable | No
|
| Housing material | Aluminium
|
| Reflector material | -
|
| Optic material | Polystyrene
|
| Optical cover/lens material | Polystyrene
|
| Fixation material | Steel
|
| Optical cover/lens finish | Mask (anti-glare)
|
| Overall length | 1195
mm
|
| Overall width | 595
mm
|
| Overall height | 11
mm
|
| Colour | White
|
| Dimensions (height x width x depth) | 11 x 595 x 1195 mm
|
| Ingress protection code | IP20
[ Finger-protected] |
| Mech. impact protection code | IK03
[ 0.3 J] |
| Initial luminous flux (system flux) | 6000
lm
|
| Luminous flux tolerance | +/-5%
|
| Initial LED luminaire efficacy | 110
lm/W
|
| Lamp colour temperature | 4000
K
|
| Colour Rendering Index | >80
|
| Initial chromaticity | (0.43, 0.40) SDCM<4
|
| Initial input power | 55
W
|
| Power consumption tolerance | +/-10%
|
| Median useful life L80B50 | 50000
h
|
| Ambient temperature range | -20 to +45 °C
|
| Maximum dimming level | Not applicable
|
| Full product code | 911401719622
|
| Order product name | RC160V LED60S 840 W60L120 PSU OC CAU
|
| Order code | 911401719622
|
| SAP numerator – quantity per pack | 1
|
| Numerator – packs per outer box | 2
|
| SAP material | 911401719622
|
| Net Weight (Piece) | 4.630
kg
|
