      SU 52
      SU 52
      Electronic series ignitor for HID lamp circuits

      SU 52

      Order code: 913710011313

      Full product code: 697013372891800

      Downloads

      Spec Sheet
      Size:508.0 kB

      See all downloads

    Specifications Show all

    General information
    Application code
    52
    Operating and electrical
    Input Voltage
    380-420 V
    Input frequency
    50 to 60 Hz
    Ignition type
    Series
    Ignition voltage (max.)
    5.0 kV
    Ignition voltage (min.)
    4.0 kV
    Response voltage
    360 V
    Mains voltage performance (AC)
    -8%-+6%
    Mains voltage safety (AC)
    -10%-+10%
    Power losses (nom.)
    5 W
    Wiring
    Ballast contact wire cross section
    2.50-4.50 mm²
    Connector type
    Screw
    Temperature
    T-ambient (max.)
    75 °C
    T-Case maximum (max.)
    105 °C
    Mechanical and housing
    Housing
    PC UL94V-2
    Approval and application
    Approval marks
    China quality certificate
    CB certificate
    Product data
    Full product code
    697013372891800
    Order product name
    SU 52
    EAN/UPC – product
    6970133728918
    Order code
    913710011313
    SAP numerator – quantity per pack
    1
    Numerator – packs per outer box
    10
    SAP material
    913710011313
    Net Weight (Piece)
    0.080 kg
